Enable DPM Mode on Capacitor

What is DPM Mode #

Enable DPM Mode #

This mode is particularly useful in industries where items need to be tracked throughout their lifespan.

To enable DPM mode:

• DataMatrix decoding is enabled - setBarcodeTypeEnabled(Barkoder.BarcodeType.datamatrix, true);
• DPM mode is set to true - setDatamatrixDpmModeEnabled(true).
• For best results, the decoding speed is set to slow - setDecodingSpeed(Barkoder.DecodingSpeed.slow)
• Resolution is set to high. - setBarkoderResolution(Barkoder.BarkoderResolution.FHD)
• A Region of Interest (ROI) is also set to optimize the viewfinder for scanning. - setRegionOfInterest(40,40,20,10)

Code Example #

In your code this would look something like:

                Barkoder.setBarcodeTypeEnabled({ type: BarcodeType.datamatrix, enabled: true });
Barkoder.setDatamatrixDpmModeEnabled({ enabled: true });
Barkoder.setDecodingSpeed({ value: DecodingSpeed.slow });
Barkoder.setBarkoderResolution({ value: BarkoderResolution.FHD });
Barkoder.setRegionOfInterest({ left: 40, top: 40, width: 20, height: 10 });
Barkoder.setRegionOfInterestVisible({ value: true });
